Dyn­acord CMS 600-3 8‑channel Compact Mixing System

Description Crosstalk: < Channel to Channel: < -80dB; Mute and Standby switch attenuation: > 100dB; Fader and FX/AUX/MON-Send attenuation: > 85dB;dB Frequency Response (-3 dB) 15Hz to 70kHz Power Requirement 100V to 240VAC, 50Hz to 60Hz Power Consumption 35W Height 4.31″ (109.6mm) Width 16.41″ (416.9mm) Depth 13.69″ (347.8mm) Weight Net 12.79lbs (5.8kg) Input Impedances MIC: 2㏀; CD In: 10㏀; All other inputs: > 15㏀; Input Sensitivity MIC: -74dBu (155μV); LINE (Mono): -54dBu (1.55mV); LINE (Stereo): -34dBu (15.5mV); CD (Stereo): -34dBu (15.5mV); Maximum SPL MIC inputs: 12dBu; Mono Line inputs: 31dBu; Stereo Line inputs: 30dBu; All other inputs: 22dBu; All other outputs: 22dBudB MIC GAIN (Stereo) 10 to 60dB MIDI Interface 5-pin DIN connector, In / Out Operating Temperature Range 5 °C… 40 °C (40 °F…105 °F) Output Impedances Phones: 47Ω; All other outputs: 75Ω (unbalanced), 150Ω (balanced) Phantom Power 48VDC Total Harmonic Distortion <0.005%
